Guangxi Ecolink Technology Co., Ltd is wholly-owned subsidiary of Ningbo Homelink Eco-iTech Co., Ltd who is one national manufacturing individual champion enterprise listed on the Shenzhen Stock Exchange(Stock Code: 301193). It is an industrial and trade enterprise who focuses on using plant fibers as raw materials, undergoes special processes and integrates research and development, manufacturing, sales, and services. Their products applied in high-end fields such as catering, industrial packaging materials and daily life are green and environmentally friendly products.
Ecolink Technology adopts global advanced production equipment and technological processes to create a garden-style zero carbon industrial park. We firmly adhere to the concept of "green mountains and clear waters are invaluable assets." and are devoted to reducing human carbon emissions and carbon footprint.
Solutions
Based on the concept of Ecolink's environmental protection, in terms of motor drive systems, WEIMA ELECTRIC provided customers with TECO energy-saving and efficient products: permanent magnet motor DVEV/DVEX, as well as supporting T310 series inverters, totally 160 pieces and output ranges from 7.5kW~132kW.
TECO permanent magnet motor DVEV/DVEX has the following features:
motors, the volume and weight are reduced by more than 35%.
High efficiency: Using high-grade magnets, the motor efficiency reaches IE4 or above.
Energy saving: Compared to ordinary asynchronous motors, it has higher efficiency at low speeds and low load rates.
Excellent torque performance: The rated output torque can still be maintained at low speeds, meeting the requirements of low speed but high torque loads.
Customer Value
So far, the installation and commissioning of all equipment have been completed and officially put into use, the services provided by WEIMA ELECTRIC already received the unanimous praise from the Ecolink's project team.
The motor and inverter use the same brand to achieve perfect matching and better operational stability. The selected TECO permanent magnet motor meets the requirements of reducing losses and controlling emissions, perfectly fitting the corporate philosophy of Ecolink Technology, lays a solid foundation for them to build a garden style zero carbon industrial park.
Thanks Guangxi Ecolink Technology Co., Ltd. for trusting WEIMA ELECTRIC, the order has been completed but the service is still ongoing. WEIMA ELECTRIC will safeguard your equipment all the time.
Schneider Electric SA, a global electrical enterprise headquartered in France, was established by the Schneider brothers in 1836 who is a global expert in energy efficiency management and automation. The group's sales volume for the FY 2016 was 25 billion EUROs, with over 160,000 employees in over 100 countries worldwide.
Schneider China has received a procurement request of frequency converter test bench equipment from the Schneider factory in the United States, to provide testing and verification for frequency converters manufactured by themselves.
Because the motors in the North American market are generally manufactured according to the NEMA (National Electrical Manufacturers Association) standards and also meet UL/CSA certified safety standards. If the test bench uses IEC/GB standard motors, it will be impossible to accurately verify the performance of the frequency converter, so the test bench needs to be equipped with motors that comply with NEMA standards.
Schneider China has extremely high requirements for the quality and after-sales support of motors. Generally the motors which can meet their needs are imported that has longer delivery time and higher prices. After weighing the pros and cons, WEIMA ELECTRIC recommended TECO NEMA motors to Schneider, which have the following advantages:
High Quality: TECO is one of the top five motor manufacturers in the world, with a market share in the top three in the United States.
After-Sales Service Guaranteed: We have a complete after-sales system in the United States.
High Cost Performance: Pure NEMA standard motors can be produced in China with high cost-performance.
Shorter delivery time: Due to motors are produced in China, the transportation time has been reduced to ensure fastest delivery.
For this project, WEIMA ELECTRIC provided 44 pieces of TECO AEHH8N NEMA motors with UL/CSA Certification of which has output power range from 0.75 to 90kW.
The services provided by WEIMA ELECTRIC have been recognized by the Schneider Electric project team.
Thanks Schneider for trusting WEIMA ELECTRIC, service has no limits, and we will continue to work hard in the future.
Weima Electric Provided a 12000KW High-voltage Water-cooled Motor to Tsingshan Holding Group.
Company Introduction
Tsingshan Holding Group’s production bases span across Zhejiang, Fujian, Guangdong, Henan, Indonesia and many other places around the world. It has established a complete stainless steel production supply chain from upstream raw materials of stainless steel, maritime logistics, nickel alloy smelting, stainless steel smelting, to downstream bar and plate processing, and international trades. In September 2021, Tsingshan Holding Group was ranked 14th on the list of China's top 500 private firms for 2021.
Project Introduction
In Indonesia Sulawesi Nickel Industry Co., Ltd., a subsidiary of Tsingshan Holding Group, their original motor brand of compressor equipped was TECO. It has been running steadily for more than 6 years. To ensure production continuity, the plant needs to procure a similar-specification high-voltage motor as a spare.
Solutions
According to the technical requirements given by Indonesia factory, Weima Electric provided a TECO HV water-cooled AEZW model with 12000KW output, consistent with the original motor. This motor offers the following advantages:
1. Using proven vacuum pressure impregnation (VPI) technology, reliable insulation system, high electrical strength of windings and long insulation life.
2. Excellent air-water cooling system with low loss, good cooling effect and low noise.
3. Rotor cast aluminum and copper bar structure allows flexible selection, low rotor dynamic imbalance, ensuring smooth operation and low vibration of the motor.
5. Reliable mechanical structure, optimized base design, and use of imported brand bearings ensuring high mechanical reliability and stable operation of the motor.
Customer Value
The equipment installation and commissioning have been completed and shipped to the Indonesian steel plant which was officially put into use. The services provided by Weima Electric have been affirmed by Tsingshan Holding Group’s project team. The existence of the spare motor ensures the stability of the production line. Moreover, the spare motor is identical to the original motor, enabling seamless integration. Weima’s solution has saved a significant amount of time and effort for Tsingshan Group’s project team because the spare motor matched the equipment perfectly without any technical modifications.
Profile of Morimatsu (Jiangsu) Heavy Industry Co., Ltd.
Morimatsu (Jiangsu) Heavy Industry Co., Ltd established in Jiangsu Province in 2007 was the largest investment project of MORIMATSU INDUSTRY CO., LTD in China. As a subsidiary of Morimatsu International Holdings Limited (stock code: 2155. HK), it is an internationally leading provider of core process equipment and integrated engineering solutions and its customer base includes leading domestic and international enterprises from multiple industries such as oil and gas, chemical, power battery raw material and environmental materials.
Introduction of PGT(Pro-Green Tech Co., Ltd.)
PGT is a manufacturer located in South Korean who produces precision chemical products such as active pharmaceutical ingredients, cosmetic additives, and special paper dyes. In 2022, it achieved sales of 40.1 billion Korean won with a profit of 3.4 billion Korean won. In last April, they attracted 36.2 billion Korean won of “Series C” investment and signed a 95 billion Korean won investment agreement for lithium battery electrolyte production with Gunsan City, Jeollabuk do in January, 2024.
Project Introduction
On June 13, 2023, Morimatsu Heavy Industry officially signed a contract with South Korean company PGT (Pro-Green Tech Co., Ltd.) for the 5000 ton lithium hexafluorophosphate project in its Shanghai headquarters office! This marks an important step in the cooperation between the two sides, and also marks the first time that Morimatsu lithium hexafluorophosphate technology has gone abroad to begin this technology promotion globally.
In August 2022, PGT began its contact with Morimatsu Heavy Industry and planned to build lithium hexafluorophosphate facilities overseas which coincided with the development strategy of Morimatsu Heavy Industry. After many rounds of negotiations and 10 months of in-depth research and consultation, both parties have finally successfully signed the contract.
Solutions
A large number of pumps and equipped electric motors used in the project need to be purchased in which the metering pumps and magnetic pumps were provided by two pump factories located in Liaoning and Zhejiang respectively. Due to the application site located in North America, the motors equipped with these pumps need to comply with the National Electrical Manufacturers Association (NEMA) standards. WEIMA ELECTRIC recommended the most cost-effective NEMA explosion-proof motor model AEHH8N produced by TECO to Morimatsu.
*NEMA Standard: The NEMA standard is a standard published by the National Electrical Manufacturers Association, primarily used to regulate the design and performance of electrical products. These standards include but are not limited to the specifications, performance and testing methods of enameled wire, as well as the safety and performance of electrical equipment. The NEMA standard is not a mandatory standard, but due to its authority and wide acceptance, it is widely used in the wire and cable and electrical equipment industries. The NEMA standard enameled wire is an important part of the NEMA standard which is used to regulate the size, material, temperature resistance level, electrical performance and other aspects of enameled wire. It is an important basis for formulating enameled wire product standards.
In addition, the NEMA standard also includes various safety and performance testing standards for electrical equipment, such as performance requirements and testing methods for flame-retardant wires and cables and mineral insulated cables. The NEMA testing standard is a comprehensive and strict standard system that not only ensures the safety and performance of electrical equipment, but also provides guidance and basis for the installation and maintenance.
In specific applications, it is important to be noted that there may be differences between the NEMA standards and other standards of other countries and regions, so caution should be taken when adopting the NEMA standards.
Chang Chun Group, founded in China Taiwan in 1949, has upheld the principles of integrity and excellence for over 55 years. With a focus on technology, quality, and customer service, it has grown into a large enterprise group in Taiwan, with products sold in over fifty countries worldwide.
Chang Chun Chemical (Jiangsu) Co., Ltd., initially invested 296.6 million USD, is located in Changshu Economic Development Zone, Jiangsu Province, covering approximately 100 hectares with over 1,000 employees. It produces twenty-five products and has facilities such as cogeneration plants and ports, current products include polyvinyl alcohol, epoxy resin, amine resin, light-induced corrosion-resistant dry film, plastic barrels, PBT, emulsion adhesives of polyvinyl acetate, and solvents etc..
Project Introduction
At the 2018 China Green Development Conference, the Ministry of Industry and Information Technology (MIIT) announced plans to accelerate the green transformation of traditional industries, emphasizing energy-saving supervision for key energy-consuming enterprises and equipment. Accordingly Chang Chun Chemical responded to MIIT's call to initiate plans to upgrade the entire factory's energy efficiency.
Solutions
Equipment involved in Chang Chun Chemical's energy efficiency upgrade include fans, pumps, mixers, conveyors, and compressors etc. Although these equipment were from different brands, after comprehensive consideration, Weima Electric provided a solution featuring explosion-proof motors of the TEB4 model with IE4 energy efficiency standards from TECO.
The upgrade project took four years to be completed from 2018 to 2022, during this period Weima Electric supplied Chang Chun Chemical with a total of 882 TECO TEB4 explosion-proof motors ranging from 0.75 kW to 75 kW, 14,409 kW in total.
Customer Value
After this energy efficiency upgrade, Chang Chun Chemical's motor efficiency improved from IE2 to IE4, not only aligning with MIIT's requirements, but also achieving energy savings and reducing running costs.
By rough calculations, after the energy efficiency upgrade for Chang Chun Chemical, their annual electricity cost saves approximately 3.42 million RMB which will reduce losses by about 3%.
Moreover, standardizing all equipment under the TECO brand will facilitate easier maintenance in the future.
Energy Saving Calculation Formula:
TECO standard IE2 motor: 55 kW-4P
Energy efficiency grade: GB3/IE2
Efficiency value: 93.5%
TECO IE4 motor: 55 kW-4P
Energy efficiency grade: GB1/IE4
Efficiency value: 95.7%
Electricity Cost Savings Calculation:
1) Total Cost = Initial Cost + Operational Cost
2) Annual Electricity Cost Savings (IE2->IE4) = kW * (100/IE2 - 100/IE4) * operating hours per year * electricity price per kWh
3) Savings Calculation Method:
Example: For a 55 kW-4P motor operating 8000 hours annually,
When upgrading from IE2 efficiency of 93.5% to IE4 efficiency of 95.7%,
WEIMA ELECTRIC Supplied HV Motors to ArcelorMittal Poland S.A.
Enterprise Introduction
ArcelorMittal S.A. is a Luxembourg-based multinational steel manufacturing corporation headquartered in Luxembourg City. It was formed in 2006 from the takeover and merger of Arcelor by Indian-owned Mittal Steel. ArcelorMittal is the second largest steel producer in the world, with an annual crude steel production of 78 million metric tons as of 2022. It is ranked 197th in the 2022 Fortune Global 500 ranking of the world's largest corporations. It employs around 154,000 people and its market capital is $20 billion. The total value of company assets is estimated to be around $94 billion.
Project Introduction
The compressor equipment units equipped with a 2250HP-2P high-voltage motor from TECO used in ArcelorMittal Poland S.A. steel plant were purchased in 2006 which has been running steadily for 18 years that has been highly recognized by the End User. Due to massive production needs, ArcelorMittal Poland S.A needs to purchase three high-voltage motors with similar specifications.
Solutions
According to the technical requirements submitted by ArcelorMittal's technical team, Weima Electric has provided it with the most cost-effective semi-enclosed (IP23) steel frame high-voltage motor model AMZK produced by WUXI TECO Elec. & Mach. Co., Ltd - TECO Factory in Wuxi, China. The semi enclosed squirrel cage induction motor was produced by TECO adopted high-quality cast iron and steel plate frame which meets the international standards of IEC in design, manufacturing and testing. Compared with similar products in China, the quality and performance is excellent and world-class and has many characteristics like a compact structure, efficient energy saving, low vibration, low noise, superior performance, safety and reliability, convenient use and maintenance, which is suitable for various industrial application sites, Mines, Pumps, Compressors, Fans and other tool machines etc..
Nordgold, formerly known as Severstal Gold, is a subsidiary of the Russian steel company Severstal which is owned by Alexey Mordashov.
In early 2012, the Russian gold mining company Nordgold separated from Russian steel company Severstal and became a publicly listed company on the London Stock Exchange through global depositary receipts.
In 2010, Nordgold acquired Société Minière de Dinguiray (SMD) in Guinea and obtained the mining rights for the Lefa Gold Mine in Guinea.
The Lefa Gold Mine located in the provinces of Siguiri and Dinguiraye, 700 kilometers away from Conakry - the capital city of Guinea, has abundant gold reserves in Guinea.
The Lefa Gold Mine began mining since 2008 and was acquired by Nordgold in July 2010.
The Lefa Gold Mine has three large mining areas and some small mining areas. In 2015, Nordgold achieved good performance at the Lefa Gold Mine in Guinea, processing 6.558 million tons of ore and producing 214.2 thousand ounces of gold. The average mining cost was USD $1,164 per ounce and the total revenue was USD $260 million.
Project Introduction
Ball Mill is the key equipment in the gold ore beneficiation process, which directly affects the efficiency and product quality of gold ore. The motor equipped on the ball mill is of utmost importance. Once the motor malfunctions or stops, the losses caused are incalculable. So Nordgold planned to purchase two 3800kW-10P motors as backup machines.
Solutions
According to the technical specifications and outline dimensions of the original motor provided by Nordgold's technical team in Russia, WEIMA ELECTRIC provided TECO AEZT - the high voltage slip ring induction motor model with a fully enclosed steel frame, which is a new series of products optimized and designed applying the technology of TECO Westinghouse in the United States. Adopting the new process, it has many advantages like simplified equipment, reliable operation, investment savings, and reduced energy consumption. It is safe and reliable to operate, easy to install and maintain, and suitable for driving various common machineries such as ventilation fans, compressors, water pumps, coal mills, steel mills, and winches etc..
Received a request from an overseas mining factory to purchase a 2500KW high-voltage synchronous motor which drives a grinding machine.
Solutions
According to the requirements from the end-user, WEIMA ELECTRIC provides customer with the TECO T series high-voltage synchronous motor. The T series motor applies the advanced synchronous motor design software SMDS from TECO Westinghouse to design motors which have splendid performance, high reliability, and easy maintenance, which can be used to drive various blowers, compressors, water pumps, rolling mills, mining mills, and other regular machines.
